- PERMANENT R5 PER 1-1/16 INCH
- IMPROVED THERMAL PERFORMANCE
- LIGHTWEIGHT & DURABLE
Halo® Interra® foam board insulation is designed for both above- and below-grade interior applications. Its core GPS foam and reflective laminate provides a permanent R-Value of R-5 per nominal inch with continuous insulation benefits when taping the seams. Interra is suitable for use on the interior side of roofs, ceilings, exterior above-grade walls, above slabs, and foundation walls. It replaces the air vapor barrier while offering high thermal resistance, impermeability to air and vapor, and prevention of moisture buildup on basement walls. Lightweight, durable, and easy to cut and install, Interra is the ideal choice for your interior wall insulation needs.
Features & Benefits
- Interior applications
- Reflective poly facer reflects heat back into home or building
- R5 per nominal inch*
- Air and moisture barrier
- GPS provides a permanent long-term R-value and won’t deteriorate over time like XPS and ISO
- Minimizes the energy loss from thermal bridging
- Light, durable, easy to cut and install
- GPS is 100% recyclable which contributes to environmental sustainability
- Available thicknesses from ½” – 2 ⅛”, 15 PSI
* Thermal performance claim based on a thickness of 1-1/16”
Specifications
| Thickness | R Value |
| ½” | R2.35 |
| 5/8” | R3 |
| ¾” | R3.53 |
| 13/16” | R4 |
| 1” | R4.7 |
| 1 1/16” | R5 |
| 1 ½” | R7.05 |
| 1 ⅝” | R7.5 |
| 2” | R9.4 |
| 2 ⅛” | R10 |
Downloads
Similar Products
No results found.
FAQs
Which way should reflective facer be installed?
The reflective facer on Halo Interra should be installed facing the interior of the building. This orientation helps to reflect radiant heat back into the living space, enhancing the insulation’s thermal performance.
Does Interra seams need to be taped?
Yes, the seams of Interra need to be taped. Taping the seams is crucial because Interra functions as a code-compliant vapor barrier, thanks to its laminate. To ensure it serves effectively as a vapor barrier, all joints between the Interra panels must be taped. Additionally, any penetrations made in the Interra membrane when fastening it should also be taped.
